HD 13i VO Tandem Roller with Vibration and Oscillation Drum #HD_13i_VO

{"brochure_or_stock":"Availability|Available for Order","promoted_feature_entity_attribute":"Promoted Features|RDO Promise","sku":"SKU|HD_13i_VO","model":"Model|HD 13i VO","feature_bullet_1":"Feature 1|Compaction with oscillation","feature_bullet_2":"Feature 2|Simple, intuitive and language-neutral control","feature_bullet_3":"Feature 3|Compact dimensions","feature_bullet_4":"Feature 4|Excellent view of drum edge, machine and construction site environment","spec_notab_clustered_specs":"Specifications|

Basic data

Series: HD CompactLine
Name: HD 13i VO
Description: Tandem roller with vibration and oscillation drum
Exhaust emissions category: EU Stage V / EPA Tier 4
Series: H285

Weights

French classification, value/class: 10,8/VT0
Max. operating weight: 11,973 lbs
Operating weight with ROPS: 9,338 lbs
Empty weight without cab, without ROPS: 8,633 lbs
Operating weight with cab: 9,889 lbs
Static linear load, rear: 91.3
Static linear load, front: 91.3 lbs/in
Axle load, rear: 4,664 lbs
Axle load, front: 4,675 lbs

Machine dimensions

Total width: 56.1 in
Total length: 116.7 in
Maximum working width: 53.1 in
Total height with cab: 107.1 in
Center distance: 76.8 in
Ground clearance, center: 12 in
Turning radius, inside: 105.9 in
Total height with ROPS: 102 in
Height loading, min.: 71.7 in

Drum dimensions

Drum type, front: Smooth/non-split
Drum type, rear: Smooth/non-split
Track offset, right: 2 in
Track offset, left: 0 in
Drum thickness, rear: 0.7 in
Drum thickness, front: 0.7 in
Drum diameter, rear: 35.4 in
Drum diameter, front: 35.4 in
Drum width, rear: 51.2 in
Drum width, front: 51.2 in

Diesel engine

Model: V2403-CR
Cylinders, quantity: 4
Exhaust emission standard: EU Stage V / EPA Tier 4
Exhaust gas after-treatment: DOC-DPF
Power ISO 14396, rpm: 2,700 rpm
Power ISO 14396, HP: 50.9 HP
Power ISO 14396, kW: 37.4 kW
Power SAE J1349, rpm: 2,700 rpm
Power SAE J1349, HP: 50.1 hp
Power SAE J1349, kW: 37.4 kW

Travel drive

Speed, infinitely variable: 0,0 - 6,8
Climbing ability, without vibration: 40 %
Climbing ability, with vibration: 30

Oscillation

Oscillation force, rear, II: 9,675 lbs
Oscillation force, rear, I: 16,200 lbs
Tangential amplitude, rear, II: 0.057 in
Tangential amplitude, rear, I: 0.057 in
Oscillation frequency, rear, II: 1,800 VPM
Oscillation frequency, rear, I: 2,340 VPM

Vibration

Centrifugal force, front, II: 8,775 lbs
Centrifugal force, front, I: 14,400 lbs
Amplitude, front, II: 0.012 in
Amplitude, front, I: 0.02 in
Vibration frequency, front, II: 3,060 VPM
Vibration frequency, front, I: 3,600 VPM

Steering

Steering, type: Articulated steering
Oscillation angle +/-: 8 °

Water-sprinkling system

Water sprinkling, type: Pressure
Fuel tank, capacity: 19.3 gal
Water tank, capacity: 75.3 gal

Tank capacity/filling capacity

Fuel tank, capacity: 19.3 gal
Water tank, capacity: 75.3 gal

Sound level

Acoustic power LW(A), measured: 102 db(A)
Sound power level L(WA), guaranteed: 106","product_brochure_url":"Product Brochure PDF URL|https://www.wirtgen-group.com/binary/full/o19665v83_HD_13i_VO_H285_enUS.pdf"}
